Unitech PA500 User Guide

45
Sharing Information
You can use your PA500 to exchange information with other mobile devices
and connect to your computer, a network, or the Internet. You have the
following options:
• Infrared connection
• Bluetooth connection
• WiFi connection
• VPN connection
• Email server connection
Infrared connection
Using the infrared (IR) port on your device to beam information, such as
contacts and appointments, from another IR-enabled device.
Setting up an IR connection
1 Activate the device’s IR port.
(1) Tap Start > Settings.
(2) On the Connections tab, tap Beam.
(3) Tap the Receive all incoming beams check box.
(4) Tap OK.
Sending and receiving information via IR
To send information via IR:
1 Switch to the program where you created the item you want to send
and locate the item in the list.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
