Unitech PA500 User Guide

53
Connecting to the Internet
Your PA500 allows you to connect to your ISP (Internet Service Provider)
and use the connection to do the following:
• Send and receive email messages
• View the Internet and Intranet
• Access Web pages
• Listen to streaming media
To connect to the Internet:
1 Ask your ISP for the following information:
• Dial-up access telephone number or access point
• User name and password
2 Tap Start > Settings.
3 On the Connections tab, do one of the following:
• Tap Connections, then in My ISP, tap the Add a new modem
connection link.
• Tap Network Cards and set up a network card or wireless network
connection.
4 Follow all onscreen instruction in the New Connection wizard.
For more information, tap Start > Help.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
