10 DS1099-077
7 CONNECTION FROM OTHER WEB BROWSERS
The camera web page can be accessed using a browser other than Internet Explorer, simply by keying in the IP address of
the camera on the navigation bar of the browser.
In this case, no additional components need to be installed and the displayed stream live consists in MJPEG video stream for
which selecting Main/Sub is not effective on the login home page.
IMPORTANT NOTE:
all the controls present on the lower bar of the live video (after login):
are available only if the Internet Explorer is used as browser after installing the ActiveX control of the camera on the PC.
These controls are not available when connecting to the web page of the camera using different browsers from IE.
8 IP CAMERA WEB PAGE CONFIGURATION
8.1 LIVE
Open Internet Explorer or other browser and enter the IP address of the IP camera (e.g.: http://192.168.100.100). The login
window appears. Observe the following figure:
The user can select the Stream Type on the access interface (this selection is only effective for Internet Explorer).
Enter User name (default: admin) and Password (default: admin), select Language and click on “Login” to access the Live
interface, as shown in the following figure.
Right-click (on Internet Explorer with ActiveX only) to select the stream to be displayed (Main Stream, Sub Stream) and to
view the bitrate.
Other Live interface buttons (on Internet Explorer with ActiveX only):
