Vanderbilt CCMS2010-IR/IRW User Manual

Camera settings
© Vanderbilt 2016
59
12.4.1 Format (Video Resolution and Rotate Type)
The Video Format setting can be found under this path: Streaming> Video For-
mat.
Video Resolution
Under Video Resolution section, the available video resolution formats are includ-
ing MJPEG and H.264. Please refer to chapter Appendix: Video Resolution - set-
ups for more combination details.
Click on <Save> to confirm the setting.
Text Overlay Settings
Users can select the items to display data including date / time / text on the live
video pane. The maximum length of the string is 20 alphanumeric characters.
Click on <Save> to confirm the Text Overlay setting.
Video Rotate Type
Users can change video display type if necessary. Selectable video rotate types
include Normal, Flip, Mirror, 90 degree clockwise, 180 degree rotate and 90 de-
gree counterclockwise.
The following is descriptions for different video rotate type.
 Flip
If select <Flip>, the image will be rotated vertically.
 Mirror
If select <Mirror>, the image will be rotated horizontally.
