1. Introduction
8 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
1.4 Marks and Symbols
Symbols
Description
Location
Dangerous voltage
Power board /
Inverter board /
Monoblock
Protective earth (Ground)
Column
Off (power: disconnected to the
Main Power Switch)
Main Power
Switch
On (power: connected to the
Main Power Switch)
Main Power
Switch
Warns ESD hazard.
MCU board /
Board package
