2.7 Installing the Warning Lamp and Door Interlock Switch
Refer to Appendix A for a complete installation guide.
▪ This system can be equipped with a warning lamp and the Door Interlock Switch
which are activated when the X-ray is energized.
▪ The warning lamp and Door Interlock Switch are not included in the equipment.
▪ The warning lamp and the Door Interlock Switch must be installed by a qualified
technician.
2.8 Installing the Emergency Stop Switch
Refer to Appendix B for a complete installation guide.
▪ Install the Emergency Stop Switch along with the main power cable in the central
distribution panel
▪ Install this switch so that it is within easy reach of the operator but cannot
be accidentally pressed.
▪ The switch must be a fool-proof model.
