6. Completing Miscellaneous Works
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 77
English
6.2 Assembling the Temple Supports and the Chinrest
Assembling the Temple Supports and the Bite Block should
be done after Acquiring a test image is completed
1. Insert the normal Chinrest and the normal Bite Block into the unit.
Chin Block-High
(Part No.7)
Chin Bite
(Part No. 12)
Chin Bite 2
(Part No. 12)
2. Insert the Temple Supports.
Temple Supports
1 set
(Part No. 5)
Cap Ear Rods
1 set
(Part No. 5)
