7. Setting up PC
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 85
English
7.4 Connecting the Cables to PC
▪ Always check the cable condition visually. Surprisingly,
unexpected errors affecting image acquisition arise from
the bad cable or its bad contact condition.
▪ Connect the regular cables for PC: keyboard, mouse,
and video in advance.
▪ The following figures and descriptions are based on the
recommended PC system described in 7.2 The
Recommended PC Requirements.
Fiber Optic
Cable
(Part No. 21)
EzDent-I USB
Key
(Part No. 1)
1. Remove the caps of the fiber optic cable.
2. Connect the Fiber Optic Cable.
3. Insert the EzDent-i USB Key into a USB port.
