Vega VEGABAR 38 User Manual

28
7 Set up with the integrated display and adjustment unit
VEGABAR 39 • Three-wire 1 x transistor or 4 … 20 mA
57536-EN-200831
7.3 Menu overview
Menu item Code acc. to
VDMA 24574-1
Basic settings
2)
Switching point output 1 SP1 25.00 %
Switch-back point output 1 RP1 23.00 %
Window upper value output 1 FH1 25.00 %
Window lower value output 1 FL1 23.00 %
Zero 4 mA ZEO Measuring range
begin
Span 20 mA SPN Measuring range
end
Extended functions EF -
Diagnostics DIA -
Menu item Code acc. to
VDMA 24574-1
Basic settings
Damping DAM
1 s
Osetcorrection OFS -
Transistor function P-N PnP
Function output 1 OU1 HNO
Switching delay time output 1 DS1
0 s
Reset delay time output 1 DR1
Reaction when malfunctions occur FER
≤3.6mA
Accept value 4 mA LRV
-
Accept value 20 mA URV
Display lighting DIS On
Indication of the switching status LED
100 %
Pressure unit UNI mbar
Unit temperature TMP °C
Menu language LG English
Bluetooth access code BT
Device-specic
access code
Protection of the parameterization COD Deactivated
Reset RES -
Menu item Code acc. to
VDMA 24574-1
Delivery status
Status STA -
Main menu
Extended functions
Diagnostics
2)
% values outputs referring to nominal measuring range
