HHPS40/10 – UK – 2002
SPECIFICATIONS HPS10 :
Maximum sample rate 10MHz for repetitive signals (2MHz for single shot events)
Maximum input amplifier bandwidth 2MHz ( -3dB at 50mV, 1V & 20V /div x1 setting)
Input impedance 1Mohm // 20pF (standard oscilloscope probe)
Maximum input voltage 100Vpeak (AC + DC), 200Vpeak-peak (AC only)
Input coupling DC, AC and GND (GND for auto zero reference)
Vertical resolution 8 bit ? 1bit linearity
Trigger modes Run, Normal, Once, Roll mode for 1s/div and slower timebase
LCD Graphics 64 x 128 pixels
Signal storage 256 samples with 2 memories, max. 125 samples visible (256 using X shift)
dBm measurement (0dBm= 0.775V in 600ohm) From -73dB tot +40dB (up to 60dB with X10 probe) +0.5dB accuracy
dBV measurements (0dBV= 1V) From -75dB tot +38dB (up to 58dB with X10 probe) +0.5dB accuracy
True-rms measurement From 0.1mV to 80V (up to 400Vrms with X10 probe) 2.5% accuracy
Peak to peak AC range (sine wave reference) 0.1mV to 160V (1mV to 1200V with x10 probe) 2% accuracy
Timebase range in 32 steps 0.2µs to 1hour / division
Input sensitivity range in 12 steps 5mV to 20V/division at X1 - 50mV to 200V/div at X10
Probe calibration output Approx. 2KHz / 5Vpp
Supply voltage 9VDC/ min 300mA adapter (unregulated) 12VDC if regulated
Batteries (option) Alkaline type AA or Ni Cd / NiMH rechargeable (5 pcs required)
Charge current for rechargeable batteries 90mA
Battery life Up to 20h with Alkaline batteries (OFF or standby current < 500µA)
Operating temperature 0 to 50°C (32 to 122°F)
Physical characteristics Dim: 105x220x35mm (4.13x7.95x1.38”) Weight 395g (14oz.) ex. Batteries
