CAUTION
FOR OIL REPLACEMENT, CONTACT ANY AUTHORISED SERVICE CENTRE AS
THEY ARE EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY
FRIENDLY AND LEGAL WAY.
Recommended products
AGIP ROTRA 80W-90
Rear hub oil
SAE 80W/90 Oil that exceeds the requirements of API GL3 specifications
Characteristic
Rear hub oil
250 cc
03_05
Tyres (03_05)
Check the tyre pressure and wear periodically (roughly every 500 km). Tyres feature
wear indicators; replace tyres as soon as these indicators become visible on the tyre
tread. Also check that the tyres do not show signs of splitting at the side or irregular
tread wear; if this occurs, go to an authorised workshop or at least to a workshop
equipped to perform the replacement.
CAUTION
TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR-
RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID-
ING DANGEROUS.
42
3 Maintenance

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vespa GTS Super 300 and is the answer not in the manual?

Vespa GTS Super 300 Specifications

General IconGeneral
Displacement278 cc
Fuel SystemElectronic fuel injection
Fuel Capacity8.5 liters
Seat Height790 mm
Front Tire120/70 - 12"
Rear Tire130/70 - 12"
Length1, 950 mm
Width755 mm
Dry Weight148 kg
Engine Type4-stroke, single-cylinder
Max Power23.8 hp @ 8, 250 rpm
Max Torque26 Nm @ 5, 250 rpm
Cooling SystemLiquid-cooled
TransmissionCVT automatic
Front SuspensionSingle arm with coil spring and hydraulic shock absorber
Rear SuspensionDouble hydraulic shock absorber with adjustable preload
Front Brake220 mm disc brake
Rear Brake220 mm disc brake
