Vespa GTS Super 300 User Manual

Rear-view mirrors
Adjust the mirrors by applying slight pressure to the side of the mirror to move it to the
desired position.
03_33
03_34
Front and rear disc brake (03_33, 03_34)
The brake disc and pad wear is automatically compensated, therefore it has no effect
on the functioning of the front and rear brakes. For this reason it is not necessary to
adjust the brakes. An excessively elastic brake lever stroke may indicate the presence
of air in the braking circuit or a failure in the braking system. In this case, mainly due
to the importance of brakes to guarantee safe riding conditions, the vehicle should be
taken to an Authorised Service Centre or Dealer.
CAUTION
THE BRAKING ACTION SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE
LEVER STROKE.
CAUTION
HAVE THE BRAKE PADS CHECKED BY THE DEALER ACCORDING TO THE
CHECKS SPECIFIED IN THE SCHEDULED MAINTENANCE TABLE. HOWEVER,
IN THE EVENT OF NOISES COMING FROM THE FRONT AND/OR REAR BRAKE
SYSTEM DURING OPERATION, IT IS ADVISABLE TO HAVE THE BRAKE SYS-
TEM CHECKED BY A PIAGGIO DEALER OR AUTHORISED SERVICE CENTRE.
AFTER REPLACING THE BRAKE PADS, DO NOT USE THE SCOOTER BEFORE
HAVING USED THE BRAKE LEVER SEVERAL TIMES IN ORDER TO ALLOW THE
PISTONS TO SETTLE AND THE LEVER STROKE TO BE SET TO THE CORRECT
POSITION.
60
3 Maintenance

Vespa GTS Super 300 Specifications

General

Displacement	278 cc
Fuel System	Electronic fuel injection
Fuel Capacity	8.5 liters
Seat Height	790 mm
Front Tire	120/70 - 12"
Rear Tire	130/70 - 12"
Length	1, 950 mm
Width	755 mm
Dry Weight	148 kg
Engine Type	4-stroke, single-cylinder
Max Power	23.8 hp @ 8, 250 rpm
Max Torque	26 Nm @ 5, 250 rpm
Cooling System	Liquid-cooled
Transmission	CVT automatic
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Rear Suspension	Double hydraulic shock absorber with adjustable preload
Front Brake	220 mm disc brake
Rear Brake	220 mm disc brake
