WARNING!
Working with, or going close to a running engine is a
safety risk. Watch out for rotating components and hot
sufaces.
WARNING!
Do not touch the connections during the start attempt:
Risk of arcing.
Do not bend over any of the batteries either.
5 Turn off the engine. Remove the start cables in the
exact opposite order to their connection.
Emergency Shifting
The descriptions refer to electrically shifted revers
gear.
If a fault occurs which prevents the revers gear from
being operated (shifted) with the control lever, it is pos-
sible to shift manually, using the description below.
WARNING!
In emergency shifting, the unit is locked in forwards
operation and the revers gear can not be disengaged
with the control lever. Forward motion can only be cut
off by stopping the engine with the ignition key or stop
button.
1 Stop the engine and remove the start key from the
key switch.
2 Note the valve (P or S) which the cable marked
“Primary” is connected. Then undo the connectors
(1 and 2) from the solenoid valves.
3 Remove the cap nut from the valve which was con-
nected to the “Primary” cable.
4 Press the button (A) on the valve.
5 Turn the button a 1/2 turn anti-clockwise (the button
is forced out by spring action).
The reverse gear is now connected for forward motion
and cannot be disengaged by the control lever.
