35
Repair - MS2 reverse gear and upper gear housing, sailboat drive
Reverse gear MS2
Output gear housing,
assembly
62. Install one of the outer bearing races in the bear-
ing housing. Use tool no. 884731 and shaft 9991801.
NOTE! Make sure that the bearing race does not go in
crookedly.
63. Turn the bearing housing over and press in the
other bearing race. Use tool no. 884731 and shaft
9991801.
64. Install the cooling water pipe and install the two
larger O-rings (1). Press the small O-ring (2) onto the
screw.
65. Apply sealant, Volvo Penta part. no. 840879-1 on
the mating face against the bearing housing.
Install the cooling water union. Check that the O-ring
is correctly aligned. Tighten the screw.
884731
9991801
884726
884731
1
2
