Group 177 Design and Function
Chassis
Springs and Suspension
For further information concerning component
specifications see service information in Group 1, “Oil and
Filter Change Intervals for Volvo Components,” publication
number 175-60, “Approved Oils Lists, Volvo Components”,
Publication Number 175–61, and appropriate vendor
literature.
Lubricate spring pins using a lithium-based grease with
EP additives and the consistency of NLG1 No.2. Fill
grease until old grease has been pushed out past the
seal on both sides and new grease can be seen flowing.
If grease is not flowing through, use a prybar to lever
down the spring ends to open up for the grease to flow.
To perform this procedure the axle must be free hanging.
Refer to the Service Information in Group 7.
Wear tolerance for the spring pin and bushing is 5 mm
(3/16 in.).
W7000449
