Wacker Neuson 1404 User Manual

BA 1404 en – Edition 2.7 * 1404b340.fm 3-75
Operation
Setting down an attachment
1 Move the attachment inward completely and position it at 5 – 10 cm (2 – 4 in)
above the ground.
2 Press switch D in position 1 (until 3rd quarter 2013 switch without locking element).
➥ The quickhitch is enabled and the buzzer sounds.
3 Press and hold the foot-operated push button E and pull the stabilizer-blade lever
backward at the same time.
➥ The quickhitch opens.
➥ Check pin F must be fully extended.
4 Retract the bucket cylinder.
➥ The attachment is lowered to the ground.
Abb. 152:
Abb. 153:
D
1
Abb. 154:
E
F
Abb. 155:
