Introduction
1.7 Type labels and component numbers
Type, quantity, and position of the labels depend on options, country and machine.
Serial number
The serial number is stamped on the machine chassis.
It is also located on the type label.
The type label is located at the front left on the machine chassis (at cab level)
Type label indications (up to serial no. AG03933)
Machine designation: HYDRAULIC EXCAVATOR
Model: ---------------
Model year: ---------------
CEE no. (EEC no.) ---------------
Output: ---------------
Serial no.: ---------------
Max. payload: ---------------
GWR: ---------------
Operating weight: ---------------
Front GAWR: ---------------
Transport weight: ---------------
Rear GAWR: ---------------
Version: ---------------
Type label indications (from serial no. AG03934)
Machine designation: HYDRAULIC EXCAVATOR
Serial no.: (machine serial no.) ---------------
Model: (machine model) ---------------
Performance: (output) ---------------
Version: (type) ---------------
Operating weight: ---------------
Transport weight: ---------------
GWR: ---------------
Max. payload: ---------------
Front GAWR: ---------------
Rear GAWR: ---------------
CEE no. (EEC no.) ---------------
Model year: ---------------
Other information – see chapter 6 Technical data on page 6-1
Abb. 1: Position of type label
Abb. 2: Type label (symbolic representation)
HYDRAULIC EXCAVATOR
Abb. 3: Type label (symbolic representation)
HYDRAULIC EXCAVATOR
