6.13 Lift capacity table (standard chassis and canopy)
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The compact excavator’s lift capacity is restricted by the settings of the pressure limiting
valves and the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
Abb. 220: Lift capacity table
A max. 3.0 m (9'-10") 2.0 m (6'-7")
B
Across stabilizer
blade
Across
side 360°
Across stabilizer
blade
Across
side 360°
Across stabilizer
blade
Across
side 360°
Lowered Raised Lowered Raised Lowered Raised
1.5 m
(4‘11”)
395*
(871*)
180
(397)
170
(375)
400*
(882*)
180
(397)
175
(386)
430*
(948*)
330
(728)
315
(694)
1.0 m
(3'-3")
380*
(838*)
165
(364)
155
(342)
405*
(893*)
180
(397)
170
(375)
615*
(1356)
315
(695)
300
(661)
0.5 m
(1‘8”)
365*
(805*)
160
(353)
155
(342)
410*
(904*)
175
(386)
165
(364)
725*
(1598*)
295
(650)
280
(617)
0.0 m
(0'-0")
350*
(772*)
165
(364)
155
(342)
385*
(849*)
170
(375)
165
(364)
715*
(1576*)
285
(628)
270
(595)
max Permissible load on extended stick
A Reach from live ring center
B Load hook height
* Lift capacity limited by hydraulic system
