Wacker Neuson 1404 User Manual

BA 1404 en – Edition 2.7 * 1404b610.fm 6-3
Technical data
6.4 Travel gear and swivel unit
6.5 Stabilizer blade
6.6 Operating hydraulics
Travel gear/swivel unit
1404/ET16
Top speed speed level 1
2.6 kph (1.6 mph)
Top speed speed level 2
4.8 kph (3 mph)
Track width
230 mm (9 in)
No. of track rollers on either side
3
Ground clearance
180 mm (7 in)
Ground pressure
0.26 kg/cm² (3.7 psi)
Upper carriage swivel speed
9 rpm
Stabilizer blade
1404/ET16
Width (folded in/out, option)
990/1300 mm (39/51 in)
Height
215 mm (8 in)
Max. lift over/under subgrade
235/270 mm (9/11 in)
Work hydraulics
1404/ET16
Control valve
9 sections
Main pressure limiting valve
for boom/bucket/stick
200
+6/-0
bar (2,901
+87/-0
psi)
Main pressure limiting valve for stabilizer blade
200
+6/-0
bar (2,901
+87/-0
psi)
Main pressure limiting valve for
swivel unit engine pressure restriction
130 bar (1,886 psi)
(PA: 150 bar; Pp: 180 bar)
(PA: 2,176 psi; Pp: 2,611 psi)
1
1. Pp = pump pressure = 180 bar (2611 psi)
PA = swivel unit pressure = 150 bar (2176 psi)
Secondary pressure limiting valve of swivel unit = 130 bar (1886 psi)
Filter
Return filter
Hydraulic reservoir capacity
20 l (5.3 gal)
Hydraulic oil quantity (system fill)
35 l (9.2 gal)
