Wacker Neuson 1404 User Manual

BA 1404 en – Edition 2.7 * 1404b320.fm 3-5
Operation
3.4 Instrument panel overview (legend)
No. Designation
Page
28
Not assigned
--
29
Not assigned
--
30
Preheating
3-11
31
Not assigned
--
32
Not assigned
--
33
Charge indicator light
3-10
34
Not assigned
--
35
Engine oil pressure
3-10
36
Coolant temperature
3-10
37
Not assigned
--
38
Not assigned
--
39
Fuel tank capacity
3-11
40
Hour meter
3-12
41
Not assigned
--
42
Ventilation (option)
3-32
43
Washer system (option)
3-33
44
Working lights
3-30
45
Rotating beacon
3-31
46
Roof lights (option)
3-30
47
Hydraulic quickhitch system HSWS (optional) - up to 3rd quarter 2013 switch without interlock
3-72
48
Driving level indicator
3-10
49
Not assigned
--
50
Not assigned
--
51
Not assigned
--
52
Not assigned
--
53
Hour meter/maintenance meter changeover
3-12
54
Service button for authorized service center
--
55
Coolant indicator (Display 2)
3-11
