Maintenance
5.17 Fluids and lubricants
Component/applica-
tion
Fluid/lubricant Specification
Season/tem-
perature
Capacities
1
Diesel engine Engine oil
API: CG-4/CH-4/CI-4
ACEA: E3, E4, E5
-15 °C (-5 °F)
+45°C (113°F)
3.4 l (0.9 gal)
ACEA E3, E4, E5 (SAE10 W 40)
2
Travelling drive Gearbox oil
API GL5
Year-round
About 0.34 l
each
(0.09 gal)
SAE 80W-90
Hydraulic oil reservoir
Hydraulic oil
HVLP46
3
Year-round
4
20 l (5.3 gal)
Biodegradable oil
5
PANOLIN HLP Synth 46
BP BIOHYD SE-46
Grease
Roller and friction bearings
6
FINA Energrease L21M
Year-round As required
Open gear
7
(live ring gears)
BP Energrease MP-MG2
Year-round As required
Grease
Roller and friction bearings
KPF2N-20
8
Year-round As required
Live ring gears
Live ring (ball bearing race)
Grease zerks
Grease zerks
Multipurpose grease
9
FINA Energrease L21 M
Year-round As required
Battery terminals
Acid-proof grease
10
FINA Marson L2
Year-round As required
Fuel tank
Diesel fuel
11
1-D/2-D ASTM D975 – 94 (USA)
Depending on
outside tem-
peratures
Summer or
winter diesel
fuel
24 l (6.3 gal)
EN 590 : 96 (EU)
ISO 8217 DMX (International)
BS 2869-A1/A2 (GB)
JIS K2204 (Japan)
KSM-2610 (Korea)
GB252 (China)
Radiator Coolant
Distilled water + antifreeze ASTM D4985
(reddish)
12
Year-round 4 l (1.06 gal)
Distilled water + antifreeze ASTM D6210
(violet)
13
Washer system Cleaning solution Water + antifreeze
Year-round 1.2 l (0.32 gal)
1. The capacities indicated are approximate values; the oil level check alone is relevant for the correct oil level
Capacities indicated are no system fills
2. According to DIN 51511
3. According to DIN 51524 section 3
4. Depending on local conditions
– see Hydraulics oil grade on page 5-37
5. Biodegradable hydraulic oil based on saturated synthetic esters with an iodine value of < 10, according to DIN 51524, section 3, HVLP, HEES
6. KF2K-25 according to DIN 51502 multipurpose lithium grease with MoS² additive
7. KP2N-20 according to DIN 51502 EP multipurpose calcium sulphonate complex grease
8. KP2N-20 according to DIN 51502 EP multipurpose calcium sulphonate complex grease
9. KF2K-25 according to DIN 51502 multipurpose lithium grease with MoS² additive
10. Standard acid-proof grease
11. Sulfur content maximal 0.05%, Cetacean number at least 45. In countries where level IIIA or higher or TIER IV or higher exhaust emission regulations apply provisionally, diesel fuels with a
maximum sulfur content of 0.0015 % (= 15 mg/kg) must be used.
12. Up to serial number WNCE0901HPAL01099
13. From serial no.WNCE0901EPAL01100
