BA 50Z3/6003 en – Edition 4.3 * 5003b510.fm 5-7
Maintenance
The fuel/water mixture must be drained directly on the fuel filter in addition.
Perform this at regular intervals according to the maintenance plan.
☞ Stop the engine.
☞ Place a suitable container under the filter.
☞ Unscrew screw A.
➥ The fuel/water mixture drains from the filter housing.
☞ Drain about 10 ml (0.3 Imp. fl. oz.) of the fuel/water mixture.
Collect the fuel/water mixture as it drains with a suitable container and dispose
of it in an environmentally friendly manner.
5.4 Engine lubrication system
If the engine oil level is too high or too low, or if an oil change is overdue, this
can cause
Loss of output and engine damage.
☞ Have the oil changed by an authorized workshop
– see chapter 5.22 Maintenance plan (overview) on page 5-57.
Checking the engine oil level
Check the oil level once a day.
We recommend checking it before starting the engine. After stopping a warm
engine, wait at least 5 minutes before checking.
• Park the machine on level and horizontal ground.
• Stop the engine.
• Raise the control lever base.
• Switch off ignition.
• Remove the ignition key and carry it with you.
• Let the engine cool down.
• Open the engine cover.
• Clean the area around the oil dipstick with a lint-free cloth.
• Pull out oil dipstick A.
• Clean it with a lint-free cloth.
• Push it back in as far as possible.
• Withdraw it and read off the oil level.
• Close and lock the engine cover.
The oil level must be between the MAX and MIN marks. However if necessary,
add oil at the latest when the oil reaches the MIN mark on the oil dipstick A.
Fig. 260: Checking the oil level
