3-30 BA 50Z3/6003 en – Edition 4.3 * * 5003b330.fm
Operation
3.19 Light system
Working lights
The switch panel for the light system is located on the instrument panel.
Switch on the working light in poor light conditions or during the night.
Fig. 72: Working light switch (up to serial no. AH02781)
44
44
Fig. 72: Working light switch (from serial no. AJ02777)
Working lights
ON
Press switch 44 down
The working light illuminates,
the indicator light in switch 44 illuminates
OFF
Press switch 44 up
The working light goes out,
the indicator light in switch 44 goes out
