6.9.3 CAN ADDRESSES FOR MCM SYSTEM
CAN Node Module Type Application
0 CAN Diagnosis Do not use
1 CAN Open Master 1 MCM CAN 1
2 CAN Open Master 2 MCM CAN 2
3 I/O Module MCM CPS
11 HU1 No. 1 Sliding table 1
12 HU1 No. 2 Sliding table 2
13 HU1 No. 3 Sliding table 3
14 HU1 No. 4 Sliding table 4
21 VU1 No. 1 Reciprocator 1
22 VU1 No. 2 Reciprocator 2
23 VU1 No. 3 Reciprocator 3
24 VU1 No. 4 Reciprocator 4
31 EPG S2 No. 1 Guns 1 and 2
32 EPG S2 No. 2 Guns 3 and 4
33 EPG S2 No. 3 Guns 5 and 6
34 EPG S2 No. 4 Guns 7 and 8
35 EPG S2 No. 5 Guns 9 and 10
36 EPG S2 No. 6 Guns 11 and 12
37 EPG S2 No. 7 Guns 13 and 14
38 EPG S2 No. 8 Guns 15 and 16
39 EPG S2 No. 9 Guns 17 and 18
40 EPG S2 No. 10 Guns 19 and 20
41 EPG S2 No. 11 Guns 21 and 22
42 EPG S2 No. 12 Guns 23 and 24
43 EPG S2 No. 13 Guns 25 and 26
44 EPG S2 No. 14 Guns 27 and 28
45 EPG S2 No. 15 Guns 29 and 30
46 EPG S2 No. 16 Guns 31 and 32
61 Light curtain portal Kontur 2, with Quattro CAN Open
62 CML 720 light curtain CML 720i height light curtain
63 CML 720 light curtain CML 720i depth light curtain, right
64 CML 720 light curtain CML 720i depth light curtain, left
65 CML 720 light curtain CML 720i code catching
81 Extension module for recipe selection (11 bit)
82 … 127 not de ned free application
