5 Troubleshooting Thermo 90
502
5.3 Failure Symptoms after Switch-off
upon Failure
NOTE
When operated with a switch the type of failure is
ind
icated by a flash code of the operation indicator light
during heater run-down.
After five short signals the long flash pulses are counted.
The heater Thermo 90 S with standard timer outputs
errors to
the timer display for indication (see 3.6.3).
The following table may also be used as representative
re
ference.
Fig. 502 Failure Symptoms after Switch-off upon Failure (Sheet 1 of 2)
Failure Symptom Failure Symptom Remedy
No function Electrical wiring,
fuses
Check fuses
Check battery connections
+ at A5 / – at A3 / + from A1
(Thermo 90)
+ at 12 / – at 9 / + at 3, connector X12
(T
hermo 90 S)
Control unit defective Replace control unit
1 Flash pulse
(no start)
Fuel system Check fuel level
Check fuel filter
Bleed fuel system
Combustion air/exhaust duct Check combustion air/exhaust duct for
f
oreign matter and clean as required
Burner Clean burner or replace as necessary
2 Flash pulses
(flame-out during operation)
Fuel supply Check fuel level
Check fuel filter
Bleed fuel system
Burner Clean burner or replace as necessary
3 Flash pulses
(low voltage)
Electrical power supply Check battery
Check electrical connections
4 Flash pulses
(flame sensor continuously
hot)
Flame sensor defective Replace flame sensor
5 Flash pulses
(flame sensor defective)
Wiring Check wiring for damage,
open connections or short circuit
Flame sensor defective Replace flame sensor
6 Flash pulses
(temperature sensor defective)
Wiring Check wiring for damage,
open connections or short circuit
Temperature sensor Replace temperature sensor
7 Flash pulses (dosing pump
d
efective / overheat protection
defective)
Coolant circuit Check coolant level
Bleed coolant circuit
Reset temperature limiter
Wiring Check wiring for damage,
open connections or short circuit
Dosing pump defective Replace dosing pump
