Xerox B1022 User Manual

6. To select Network Features, press the Down Arrow button twice, then press the OK button.
7. To select a Background Suppression option, press the Down Arrow button as many times as
necessary to access the option, then press the OK button.
Note: For details about each Background Suppression option, refer to Background
Suppression Options.
• OFF
• Auto
• Enhance Level 1
• Enhance Level 2
• Erase Level 1
• Erase Level 2
• Erase Level 3
• Erase Level 4
A Saved message appears with a check mark for the selected background suppression option.
Background Suppression Options
Options Description
OFF Indicates that the Background Suppression feature is not activated. When this
feature is OFF, the printer adjusts the image quality according to the Enhance
and Erase settings.
Auto The printer examines a sample of the document that you are scanning
automatically, then adjusts the image quality. This setting can produce a
document of good quality, even when your original document is of poor
quality.
Enhance Level 1 Provides the lowest level of background enhancement.
Enhance Level 2 Provides the highest, vivid level of background enhancement.
Erase Level 1 Provides the darkest possible background.
Erase Level 2 Provides the highest, vivid level of background enhancement.
Erase Level 3 Provides a lighter background than Level 2.
Erase Level 4 Provides the lightest background of all the levels.
SSeettttiinngg tthhee OOrriieennttaattiioonn ooff tthhee OOrriiggiinnaall DDooccuummeenntt
This procedure applies only if you are using a printer that has an optional document feeder. If you
are loading the document on the document glass, the orientation depends on the direction in which
you load the document.
To set the orientation of the original document:
1. At the printer, load the original document on the document glass.
2. At the printer control panel, press the Clear All button.
3. Press the Scan To button.
4. To select Network, press the Down Arrow button, then press the OK button.
Xerox
®
B1022 Multifunction Printer
User Guide
65
Using the Services

Xerox B1022 Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Watermark printing	Yes
Time to first page (black, normal)	9.1 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	11 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7.8 s
Copy speed (black, normal quality, A4)	22 cpm
Faxing	No
Scan to	E-mail, FTP, PC, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed scanner
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIFF
Document formats supported	PDF
Total input capacity	350 sheets
Total output capacity	250 sheets
Maximum input capacity	600 sheets
Sound power level (standby)	30 dB
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1100 W
Power consumption (off)	2 W
Power consumption (ready)	80 W
Power consumption (sleep)	1 W
Power consumption (average operating)	550 W
Energy Star Typical Electricity Consumption (TEC)	1.2 kWh/week
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Product color	Black, White
Market positioning	Business
Package depth	750 mm
Package width	771 mm
Package height	600 mm
Package weight	32000 g
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	PCL 6, PostScript
Paper tray media types	Bond paper, Heavy paper, Letterhead, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm), Tabloid (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B4
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Included cartridge capacity (black)	2500 pages

Weight and Dimensions

Depth	555.3 mm
Width	560 mm
Height	417 mm
