7.1 Replacing Consumables 129
5. Release the levers at both ends of the
fuser.
6. Hold both sides of the installed fuser, and
pull it inward slightly and then upward to
remove.
7. Unpack a new fuser and remove the tag
from the new fuser.
8. With the connector of the fuser toward the
slot, lower the fuser and then push the
connector into the slot firmly.
Note
• Hold either side of the fuser with both hands.
• Make sure that the fuser is firmly fixed in the slot and
cannot be moved easily.
9. Lock both levers at the ends of the fuser.
To Next Page
