Xerox DocuPrint C3300 DX User Manual

7.1 Replacing Consumables 133
5. Repeat steps 3-4 and remove the other
feed roller from inside of the printer.
6. Align the hole of the new feed roller with the
axle.
7. Slide the feed roller along the axle so that
the protrusions fit completely into the slots
on the axle.
8. Replace the tray into the printer.
Replacing the Feed Roller in the 550 Sheet Feeder
1. Pull the tray out of the printer until it stops.
Hold the tray with both hands, lift the front
slightly, and remove it from the printer.
2. Remove any paper in the tray.
To continue replacing the feed roller, refer to steps 3-8 of "Replacing the Feed Roller in the
Tray" (P. 130) and steps 3-8 of "Replacing the Feed Roller in the Printer" (P. 132).

Xerox DocuPrint C3300 DX Specifications

General

Brand	Xerox
Model	DocuPrint C3300 DX
Category	Printer
Language	English
