Xerox VersaLink B600 User Manual

CONFIGURING AIRPRINT
AirPrint
®
is a software feature that allows you to print from wired or wireless Apple iOS-based mobile devices and
Mac OS-based devices without the need to install a print driver. AirPrint-enabled printers allow you to print directly
from a Mac, an iPhone, iPad, or iPod touch. You can use AirPrint to print from a wired device or a wireless device
without using a print driver.
Note:
• Not all applications support AirPrint
®
.
• Wireless devices must join the same wireless network as the printer.
• For AirPrint to function, both IPP and Bonjour
®
(mDNS) protocols must be enabled.
• The device that submits the AirPrint job must be on the same subnet as the printer. To allow devices to
print from different subnets, configure your network to pass multicast DNS traffic across subnets.
• The Mac OS device must be Mac OS 10.10 or later.
• AirPrint-enabled printers work with all models of iPad, iPhone (3GS or later), and iPod touch (third
generation or later), running the latest version of iOS.
1. At your computer, open a Web browser. In the address field, type the IP address of the printer, then press EEnntteerr
or RReettuurrnn.
Note: If you do not know the IP address for your printer, refer to Finding the IP Address of Your Printer.
2. In the Embedded Web Server, click HHoommee >> CCoonnnneeccttiivviittyy.
Note: If this feature does not appear, log in as a system administrator.
3. For Mobile Printing, click AAiirrPPrriinntt.
4. To enable AirPrint, click the EEnnaabbllee toggle button.
Note: AirPrint is enabled by default when IPP and Bonjour
®
(mDNS) are both enabled.
• To change the printer name, in the Name field, enter a new name.
• To enter a location for the printer, in the Location field, enter the location of the printer.
• To enter a physical location or address for the printer, in the Geo-Location field, enter the geographic
latitude and longitude coordinates in decimal form. For example, use coordinates such as 45.325026,
-122.766831 for a location.
5. Click OOKK.
6. To activate your changes, at the prompt, click RReessttaarrtt NNooww.
CONFIGURING GOOGLE CLOUD PRINT
Google Cloud Print allows you to print documents that are stored in the cloud without using a print driver.
Xerox
®
VersaLink
®
B600/B610 Printer User Guide 49
Getting Started

Xerox VersaLink B600 Specifications

General

Package weight	28000 g
Country of origin	Vietnam
Maximum resolution	1200 x 1200 DPI
Optional connectivity	Wireless LAN
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Sustainability certificates	ENERGY STAR
Operating relative humidity (H-H)	10 - 85 %
Printing colors	Black
Maximum duty cycle	250000 pages per month
Recommended duty cycle	0 - 20000 pages per month
Number of print cartridges	1
Page description languages	HP-GL, PCL 5e, PCL 6, PostScript 3, TIFF, XPS
USB port	Yes
Package depth	634 mm
Package width	580 mm
Package height	607 mm
Print technology	Laser
Warm-up time (from sleep mode)	35 s
Time to first page (black, normal)	6.3 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Duplex print speed (black, normal quality, A4/US Letter)	49.3 ppm
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	150 sheets
Custom media width	76.2 - 190 mm
Custom media length	216 - 356 mm
Duplex media weight	60 - 176 g/m²
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Maximum ISO A-series paper size	A4
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP, HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP, FTP
Processor cores	2
Processor family	ARM Cortex
Sound power level (standby)	27.1 dB
Sound pressure level (printing)	56.8 dB
Current rating	8 A
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	72 W
Power consumption (printing)	900 W
Control type	Touch
Product color	White
Market positioning	Business
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Cables included	AC
Included cartridge capacity (black)	1 pages
Compatibility	VersaLink B600/B610

Weight and Dimensions

Depth	465.5 mm
Width	427.4 mm
Height	443.4 mm
