Configuring the BIOS
29
Standard CMOS Features
Menu
The Standard CMOS Features menu is used to configure the standard CMOS
information, such as the date, time, HDD model, and so on. Use the Page Up
and Page Down keys to scroll through the options or press Enter to display the
sub-menu. Use the arrow keys to position the selector in the option you
choose. To go back to the previous menu, press Esc.
The information shown in Item Help corresponds to the option highlighted.
Figure 6. Standard CMOS Features Menu
Note: Note that all data in white is for information only, data in yellow is changeable,
data in blue is non-changeable, and data in a red box is highlighted for
selection.
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7:Defa
IDE Channel (.) Master [None]
IDE Channel (.) Slave [None]
SATA Channel 1 Master [None]
SATA Channel 2 Master [None]
SATA Channel 3 Master [None]
SATA Channel 4 Master [None]
SATA Channel 5 Master [None]
SATA Channel 6 Master [None]
Drive A [1.44, 3.5 in.]
Halt On [All , But Keyboard]
Base Memory 640K
Extended Memory 1047552K
Total Memory 1048576K
Date (mm:dd:yy) Sat, Jul 01 2006
Time (hh:mm:ss) 12 : 48: 23
Item Help
Main Level
Change the day, month,
year and century
Phoenix – AwardBIOS CMOS Setup Utility
