System Voltages
Select System Voltages from the Advanced Chipset Features menu and press
Enter to display the System Voltages menu.
Figure 12. System Voltages Menu
 CPU Core
Use the Page Up and Page Down keys to scroll through the voltages or select
[Auto] to automatically set the voltage level for the CPU Core.
 CPU FSB
Use the Page Up and Page Down keys to scroll through the voltages or select
[Auto] to automatically set the voltage level for the CPU FSB.
 Memory
This function defines the voltage level for the DRAM. Use the Page Up and
Page Down keys to select a voltage or select [Auto] to automatically set the
voltage.








 :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7:Defaults
Parameters Settings Current Value
CPU Core [Auto] 1.28
CPU FSB [Auto] 1.2V
Memory [Auto] 1.85V
nForce SPP [Auto] 1.30V
nForce MCP [Auto] 1.50V
HT nForce SPP <-> MCP [Auto] 1.20V
nForce MCP Auxiliary [Auto] 1.50V
GTLVREF Lane 0 [Auto] +00mv
GTLVREF Lane 1 [Auto] +00mv
GTLVREF Lane 2 [Auto] +00mv
GTLVREF Lane 3 [Auto] +00mv
Item Help
Main Level 




Voltage level for CPU
Core (CPU VID)
Phoenix – AwardBIOS CMOS Setup Utility
System Voltages
