Installing Alveo Data Center Accelerator
Cards in Server Chassis
For hardware and soware installaon procedures, see the Alveo U50 Data Center Accelerator
Card Installaon Guide (UG1370).
Because each server or PC vendor's hardware is dierent, for physical board installaon
guidance, see the manufacturer’s PCI Express
®
board installaon instrucons.
FPGA Configuration
The Alveo U50 accelerator card supports two UltraScale+™ FPGA conguraon modes:
• Quad SPI ash memory
• JTAG (through maintenance port)
The FPGA bank 0 mode pins are hardwired to M[2:0] = 001 master SPI mode with pull-up/down
resistors.
At power up, the FPGA is congured by the QSPI NOR ash device (Micron
MT25QU01GBB8E12-0SIT) with the FPGA_CCLK operang at a clock rate of up to 85 MHz
using the master serial conguraon mode.
If the JTAG cable is plugged in, QSPI conguraon might not occur. JTAG mode is always
available independent of the mode pin sengs.
For complete details on conguring the FPGA, see the UltraScale Architecture Conguraon User
Guide (UG570).
Table 3: Configuration Modes
Configuration Mode M[2:0] Bus Width CCLK Direction
Master SPI 001 x1, x2, x4 FPGA output
JTAG Not applicable – JTAG overrides x1 Not applicable
Chapter 3: Card Installation and Configuration
UG1371 (v1.2) December 18, 2019 www.xilinx.com
Alveo U50 Accelerator Card User Guide 15
