Xinje DP3C Series User Manual

16
Parameter
Address
Contents
Note
U0-13
0x100D
48~62; 63: direction bit
U0-14
0x100E
Position offset
0~15
Command pulse
U0-15
0x100F
16~31
U0-16
0x1010
Single turn
encoder counting
0~15
Encoder pulse
U0-17
0x1011
16~31
U0-18
0x1012
Single turn pulse
counting
0~15
Command pulse
U0-19
0x1013
16~31
U0-20
0x1014
Pulse turns
0~15
U0-21
0x1015
16~31
U0-22
0x1016
Encoder turns
0~15
U0-23
0x1017
16~31
U0-24
0x1018
Feedback electric angle
U0-25
0x1019
Setting electric angle
U0-26
0x101A
Phase A feedback current
mA
U0-27
0x101B
Phase B feedback current
mA
U0-28
0x101C
Reference feedback current
mA
U0-29
0x101D
Phase A setting current
mA
U0-30
0x101E
Phase B setting current
mA
U0-31
0x101F
Reference setting current
mA
U0-32
0x1020
Bus voltage
V
Group U1
Parameter
Address
Contents
Note
U1-00
0x1100
Current alarm code
U1-01
0x1101
Phase A current when alarm occurs
U1-02
0x1102
Phase B current when alarm occurs
U1-03
0x1103
Reference current when alarm occurs
U1-04
0x1104
Bus voltage when alarm occurs
U1-05
0x1105
Position offset when alarm occurs
U1-06
0x1106
Speed value when alarm occurs
U1-07
0x1107
The time when alarm occurs
U1-08
0x1108
The time when alarm occurs
U1-09
0x1109
This time operation error code quantity
U1-10
0x110A
Last second alarm code
U1-11
0x110B
Last third alarm code
U1-12
0x110C
Last fourth alarm code
U1-13
0x110D
Last fifth alarm code
U1-14
0x110E
Last sixth alarm code
U1-15
0x110F
Reserved
U1-16
0x1110
Reserved
U1-17
0x1111
Reserved
U1-18
0x1112
Reserved
U1-19
0x1113
Reserved
U1-20
0x1114
Reserved
U1-21
0x1115
Reserved
