XVision X2RxN - Record; Privacy Zone

11
4.2.1.1.4 Privacy Zone
Privacy Zone is for setting areas that you do not want to be visible on the live view (Public
areas)
1. Select the number of the zone to be set (maximum 4 zones can be set for single channel)
2. Click “Setup” to adjust the position of the zone.
3. After finish setting, right click the mouse to return to the “Privacy Zone” page.
4. Click “Save” to save the setting.
4.2.1.2 Record
4.2.1.2.1 Record
Go to “Main Menu” → “Record” → “Record”
 Channel：Set the desired channel in the
drop-down menu
 Record：Set up the record status
(Enable/Disable) of each channel.
 Stream Mode：Select Mainstream or Sub
stream.
 Prerecord：“Enable” status supports pre-
record for motion detection record or I/O
trigger record.
