Chapter 2 X2RxN Connection
2.1 HDD Installation
HDD Installation:
(1) Make sure your X2RxN is not powered, now you can remove the screws on both
sides of the X2RxN and the rear panel. Slide the cover away from the front panel and lift
off.
(2) Within the X2RxN original box you will have the SATA cables for data and a Molex
cable for power, connect these to the main board. Install the HDD(s) and screw it down
using the provided screws. Once secure please connect the cables to the back of the
HDD.
(3) You can now place the cover back on, please take care to put all screws back into the
holes they came from.
2.2 IPC (IP Camera) and Monitor Connection
The IPC will require CAT5/6 Patch cables and the Monitor out connections are either
VGA or HDMI, please refer to table showing rear connections on X2RxN.
2.3 Power Supply Connection
Please use only the supplied power adapter to connect to the X2RxN. Please refer to
table showing rear connections.
Chapter 3 X2RxN Boot up
3.1 System Initialization
After giving power to the X2RxN, please note some units have a power on switch, please
refer to the Rear panel section for more details on the unit you have. Once booted you will
see the boot screen as shown.
