Yaesu FTDX10 User Manual

EXTENSION SETTING
- SD CARD -
MEM LIST LOAD
Function: Load the Memory Channel information
saved on the SD memory card into the
transceiver.
MEM LIST SAVE
Function: Save the Memory Channel information
to the SD memory card.
MENU LOAD
Function: Load the Setting Menu information
saved on the SD memory card into the
transceiver.
MENU SAVE
Function: Save the Setting Menu information to
the SD memory card.
INFORMATIONS
Function: Display information from SD Memory
Card.
Description: Displays the total capacity and free
space of the SD Memory Card.
FIRMWARE UPDATE
Function: Update the rmware of the FTDX10.
Description: When a new firmware update for
the FTDX10 is available, go to the
YAESU web site to download the
programming data and update the
FTDX10 Firmware.
FORMAT
Function: Format (initialize) the SD memory card.
Description: Format a micro SD Memory Card for
use with this transceiver.
EXTENSION SETTING
- SOFT VERSION -
Description: Displays the software version.
EXTENSION SETTING
- CALIBRATION -
CALIBRATION
Function: Display touch position calibration.
Description: If the touch position and the opera-
tion are di󰀨erent, that is touch does
not work or another function works,
perform touch position calibration of
the TFT display.
1. Select [CALIBRATION] then press the [FUNC]
knob.
2. Touch “+” at the top left of the display.
To cancel the calibration, press the [S.MENU]
key.
3. Touch “+” displayed at another place.
4. Repeat step 3 and nally touch “+” in the cen-
ter of the display to complete the calibration.
EXTENSION SETTING
- RESET -
MEMORY CLEAR
Function: Memory reset
Description: Only the information stored in the
Memory Channel is initialized (all
erased).
The contents of the memory channel “M-01” will
return to the initial setting “7.00.000 MHz, LSB”
and cannot be deleted.
Memory information can be saved on the SD
card.
MENU CLEAR
Function: Setting Menu reset
Description: Only the contents of the Setting
Menu is initialized (factory default).
Information in the setting menu can be saved on
the SD card.
ALL RESET
Function: ALL reset
Description: The Memory, Setting Menu and all
other settings are initialized and set
to the factory default.
107

Yaesu FTDX10 Specifications

General

Type	HF/50 MHz Transceiver
Antenna Impedance	50 Ohms
Supply Voltage	13.8 V DC ±15%
IF DSP	Yes
Modes	AM, FM
RF Power Output	100 W (HF)
Display	5-inch Full-Color Touch Panel
Dimensions	266 x 263 mm
Weight	5.9 kg
IF Rejection	70 dB or better
Image Rejection	70 dB or better
Receiver Type	SDR (Software Defined Radio)
