Yaesu FTDX10 User Manual

RADIO SETTING
- MODE PSK/DATA -
AF TREBLE GAIN
Function: Sets the amount of gain in the treble
range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the treble
range can be set in the range of -20
to +10.
AF MIDDLE TONE GAIN
Function: Setting the amount of gain in the mid-
dle range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the middle
range can be set in the range of -20
to +10.
AF BASS GAIN
Function: Setting the amount of gain in the bass
range of the received audio.
Available Values: -20 to +10
Default Setting: 0
Description: The amount of gain in the bass
range can be set in the range of -20
to +10.
AGC FAST DELAY
Function: Sets the AGC-FAST DELAY voltage
decay characteristics for PSK/DATA
mode.
Available Values: 20 - 4000msec
Default Setting: 160msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
AGC MID DELAY
Function: Sets the AGC-MID DELAY voltage
decay characteristics for PSK/DATA
mode.
Available Values: 20 - 4000msec
Default Setting: 500msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
AGC SLOW DELAY
Function: Sets the AGC-SLOW DELAY voltage
decay characteristics for PSK/DATA
mode.
Available Values: 20 - 4000msec
Default Setting: 1500msec
Description: Sets the AGC voltage decay char-
acteristics in 20msec steps after the
input signal level becomes lower
than the AGC detection level and the
HOLD time has expired.
PSK TONE
Function: Set the PSK tone
Available Values: 1000 / 1500 / 2000 Hz
Default Setting: 1000Hz
DATA SHIFT (SSB)
Function: Sets the carrier point in DATA mode.
Available Values: 0 - 3000 Hz
Default Setting: 1500 Hz
Description: The frequency can be set in steps of
10Hz.
LCUT FREQ
Function: Sets the low-frequency cuto󰀨 audio l-
ter in DATA mode.
Available Values: OFF / 100Hz - 1000Hz
Default Setting: 300
Description: The cutoff frequency can be set at
50Hz increments between 100Hz
and 1000Hz.
LCUT SLOPE
Function: Sets the slope of the low-frequency
cuto󰀨 audio lter in DATA mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
HCUT FREQ
Function: Sets the high-frequency cutoff audio
lter in DATA mode.
Available Values: 700Hz - 4000Hz / OFF
Default Setting: 3000Hz
Description: The cutoff frequency can be set at
50Hz increments between 700Hz
and 4000Hz.
HCUT SLOPE
Function: Sets the slope of the high-frequency
cuto󰀨 audio lter in DATA mode.
Available Values: 6dB/oct / 18dB/oct
Default Setting: 18dB/oct
DATA OUT LEVEL
Function: Sets the level of the receive DATA sig-
nal output from the RTTY/DATA jack.
Available Values: 0 - 100
Default Setting: 50
91

Yaesu FTDX10 Specifications

General

Type	HF/50 MHz Transceiver
Antenna Impedance	50 Ohms
Supply Voltage	13.8 V DC ±15%
IF DSP	Yes
Modes	AM, FM
RF Power Output	100 W (HF)
Display	5-inch Full-Color Touch Panel
Dimensions	266 x 263 mm
Weight	5.9 kg
IF Rejection	70 dB or better
Image Rejection	70 dB or better
Receiver Type	SDR (Software Defined Radio)
