17
Authenticate (activate) the WIRES-X server
If the WIRES-X server authentication (activation) has not been completed on the personal computer to be used, the
“WIRES ID Activation” screen opens automatically.
1. Enter the “Node ID” and “Room ID” (both are 5-digit numbers)
.
• Be sure to connect the transceiver started in “Portable digital node mode
”
or “Portable HRI mode
”
to a PC. Node
ID and Room ID cannot be entered when the RADIO ID is not automatically entered in the Serial Number box.
• “RADIO ID
”
of the transceiver connected to the PC is automatically displayed in the serial number box
. If “RADIO
ID
”
is not displayed, check the connection between the transceiver and the PC again.
• Remove the HRI-200 interface unit from the PC when using the Portable Digital Node function.
• The Node ID and the Room ID are described in the e-mail received when the user registration is completed.
The Radio ID is automatically entered
when a transceiver started in “Portable
digital node mode” or “Portable HRI
mode” is connected to the PC.
Enter the 5 digits of the "WIRES-X ID
Number" and "WIRES-X ROOM ID
Number" that are included in the
WIRES-X new registration email.
When the Serial No. and DTMF ID
fields are filled, you can click the
ID Entry button.
2. Click [ID Entry]
.
When activation is completed, information on registration is automatically displayed for “User ID”, “Call Sign”, “City”,
“State”, and “Country”.
3. Click [OK].
The information of the User ID is saved on the computer and “Settings” window will appear.
On this screen the settings such as “Comment” of your station may be added to display in the ID list.
4. Click [OK].
The “Settings” window closes and the “Main Screen” will appear.
When using it in “Direct Operation”, “Transceiver settings (Access Point only)” (page 18) is not necessary, so the
initial setting is completed.
Proceed to
“Basic Operation” (page 20).
