Programming 2200 YRM 1067
20. BATTERY MODEL = battery-type of input switch,
ON/OFF. ON = flooded battery (input closed), OFF
= sealed battery (input open).
21. BATTERY CHARGE = battery charge indication, %.
SET OPTION MENU
ON The truck has three performance
modes, each with a fixed set
of parameters. This function
is enabled by setting DRIVE
MODES = ON.
DRIVE
MODES
OFF DRIVE MODES disabled.
ZAPI™ HANDSET
The ZAPI™ handset must be connected to the con-
troller before turning on the key. The handset must have
an adapter harness to connect to the controller. The
handset and adapter harness are available from your
Yale dealer. Connect the handset to plug B. The hand-
set can remain connected to the controller while run-
ning, and the parameters can be changed in real time.
In this case, it is necessary to go in a standby condition
(truck at rest) before switching OFF the controller in or-
der to store the new values in the EEPROM.
This section describes the ZAPI™ handset functions.
Six buttons provide the capability of changing or reading
the parameters.
1
Roll-Up Push to scroll up.
2
Roll-Down Push to scroll down.
3
Enter Push to enter a submenu
or to confirm a change.
4
Out Push to exit a selected
menu or to refuse a
change.
5
Set-Up Push to increase a
parameter value.
6
Set-Down Push to decrease a
parameter value.
NOTE: After a modification, save the new values by
pushing out, then enter to confirm. (Screen prompts
will guide the user.)
To navigate the menu options, numbers inside the trian-
gles in the following map correspond to the same num-
ber on the handset keyboard buttons. The orientation of
the triangle indicates the way to the next function. See
Figure 3.
NOTE: Connect and disconnect the handset only with
the key switch in the OFF position.
For additional handset description, see Figure 4.
6
To Next Page
