Troubleshooting 2200 YRM 1067
Troubleshooting
Dash Display
Controller LED Handset or PC
LCD display Red LED
Red LED Fault Indicator Located at base of motor
controller.
Error codes stored under Main Menu Alarms
(Trucks equipped with
optional dash display)
(Trucks without dash
display)
Message displayed on Handset or PC
CORRESPONDING SCHEMATIC SHOWING
CIRCUITS TO BE CHECKED OR AFFECTED
COMPONENT(S)
CONDITION
TRUCK RESPONSE
POSSIBLE C
AUSES AND TEST PROCEDURES
LOGIC
(Brief des
cription of the reason behind truck
exhibited
malfunction.)
NOTE: General error code information is provided by the Dash Display and Red LED at the base of the controller.
In most instances, it will be necessary to use a handset or a PC to further define the possible causes and test
procedures.
