INSTRUMENT AND CONTROL FUNCTIONS
3-8
3
EAU13730
Steering lock
To lock the steering
1. Turn the handlebar all the way to
the right.
2. Open the steering lock cover, and
then insert the key.
3. Turn the key 1/8 turn counterclock-
wise, push it in while turning the
handlebar slightly to the left, and
then turn the key 1/8 turn clock-
wise.
4. Check that the steering is locked,
remove the key, and then close the
lock cover.
To unlock the steering
1. Open the steering lock cover, and
then insert the key.
2. Push the key in, turn it 1/8 turn
counterclockwise so that it moves
out, and then release it.
3. Remove the key, and then close
the lock cover.
EAU14220
Rider seat
To remove the rider seat
Remove the bolts, and then pull the rid-
er seat off.
To install the rider seat
1. Insert the projection on the front of
the rider seat into the seat holder
as shown.
1. Steering lock
1. Bolt
