PERIODIC MAINTENANCE AND MINOR REPAIR
6-9
6
● Make sure that no foreign mate-
rial enters the crankcase.
9. Start the engine, and then let it idle
for several minutes while checking
it for oil leakage. If oil is leaking, im-
mediately turn the engine off and
check for the cause.
10. Turn the engine off, and then
check the oil level and correct it if
necessary.
EAU32743
Cleaning the air filter element
The air filter element should be cleaned
at the intervals specified in the periodic
maintenance and lubrication chart.
Clean the air filter element more fre-
quently if you are riding in unusually
wet or dusty areas.
1. Remove the bolts and loosen the
air filter case joint clamp screw.
2. Disconnect the hoses from the air
filter case, and then remove the air
filter case.
1. Bolt
1. Air filter joint clamp screw
2. Air filter case cover
3. Air filter case
1. Hose
2. Air filter case
U2UJ23E0.book Page 9 Wednesday, May 11, 2005 11:30 AM
