TOP COWLING LOCK LEVERS
3
To remove the engine top cowling, pull
up the front and rear lock levers. Then lift
off the cowling. When replacing the cowl-
ing, check to be sure it fits properly in the
rubber seal. Then lock the cowling again
by moving the levers downward.
4/5
To remove the engine top cowling, push
the lock lever downward. Then lift off the
cowling. When replacing the cowling,
check to be sure it fits properly in the rub-
ber seal. Then lock the cowling again by
moving the lever upward.
301035
301036
3
4/5
