Trouble recovery
132
(5) Securely install the fuse box cover in its
original position.
(6) If the accessory fuse or bilge fuse was
replaced, install the fuse holder.
(7) Close the engine hood.
Towing the boat
WARNING
 The operator of the towing boat must
keep speed to a minimum and avoid
traffic or obstacles which could be a
hazard to either boat.
 The towing line should be long enough
so the towed boat will not collide with
the towing boat when slowing down.
The boat should be towed only if it becomes
inoperative.
The towing rope should be long enough so
that the boat will not collide with the towing
boat when slowing down. A good rule of
thumb is a tow rope which is three times the
combined length of the towing boat and the
boat.
Tow the boat using the bow eye only. Tow the
boat at a no-wake speed. NOTICE: Do not
tow the boat at speed fast enough to leave
a wake (8 km/h, 5 mph). Severe engine
damage could result because water can
flood the non-operating engine through
the water intake.
1 Bow eye
Fuse amperage:
Electronic throttle valve fuse:
10 A
Fuel pump fuse:
10 A
Main relay drive fuse:
10 A
Main fuse:
20 A
Battery fuse:
30 A
Accessory fuse:
20 A
Bilge pump fuse:
3 A
1
SportsBoat_F4V10.book Page 132 Tuesday, July 3, 2018 1:03 PM
Downloaded from ManualsNet.com search engine

Yamaha AR190 2019 Specifications

General

Seating Capacity	8 persons
Hull Material	Fiberglass
Horsepower	180 hp
Beam	8 ft 2 in
Draft	15 in (0.38 m)
Engine	Yamaha 1.8L High Output
