Equipment operation
72
Bimini top (AR195/AR190)
Setting up the bimini top
To set up the bimini top:
(1) Remove the storage cover, and then un-
wrap the bimini top.
1 Storage cover
(2) Pull the front of the bimini top toward the
bow, and then open the flap and pull out
the front support poles from the bimini
top.
1 Front support pole
2 Flap
(3) Insert the front support poles into the
mounting holes in the wakeboard tower.
1 Mounting hole
2 Front support pole
(4) Pull the rear of the bimini top toward the
stern, and then unhook the rear support
poles from the main pole.
1 Rear support pole
2 Main pole
1
1
2
2
1
1
2
SportsBoat_F4V10.book Page 72 Tuesday, July 3, 2018 1:03 PM
Downloaded from ManualsNet.com search engine

Yamaha AR190 2019 Specifications

General

Seating Capacity	8 persons
Hull Material	Fiberglass
Horsepower	180 hp
Beam	8 ft 2 in
Draft	15 in (0.38 m)
Engine	Yamaha 1.8L High Output
