Yamaha AR190 2019 User Manual

40
Instrument operation
Switches
Name Function Page
1 Blower switch Turns the blower on or off to ventilate the engine compart-
ment.
92
2 Courtesy light switch Turns the courtesy light and on or off. 41
3 Navigation and anchor
lights switch
Turns the anchor light and bow light on or off. 41
4 Bilge pump switch Turns the bilge pump on or off. 84
5 Horn switch Activates the horn. The horn can be used to signal other
boats as required by the “Rules of the road”.
20
6 No-wake mode/cruise
assist switch
Activates and sets the cruise assist, no-wake mode, and
reverse RPM control.
42
HORNBILGENAV/ANC
CTSY
LIGHTS
BLOWER
1 2 3 4 5 6
SportsBoat_F4V10.book Page 40 Tuesday, July 3, 2018 1:03 PM
Downloaded from ManualsNet.com search engine

Yamaha AR190 2019 Specifications

General

Seating Capacity	8 persons
Hull Material	Fiberglass
Horsepower	180 hp
Beam	8 ft 2 in
Draft	15 in (0.38 m)
Engine	Yamaha 1.8L High Output
