Pre-operation checks
91
AR190/SX190 (3-star models)
1 Dipstick
1 Maximum level mark
2 Minimum level mark
AR190/SX190 (4-star models)
1 Dipstick
1 Maximum level mark
2 Minimum level mark
Battery check
Make sure that the battery terminals are not
damaged and that the battery leads are con-
nected properly. WARNING! The battery
must always be fully charged and in good
condition. Loss of battery power may
leave you stranded. Never operate the
boat if the battery does not have sufficient
power to start the engine or if it shows any
other signs of decreased power.
1 Negative (–) battery terminal
2 Black lead
3 Positive (+) battery terminal
4 Red lead
1
2
1
1
2
1
4
3
2
1
SportsBoat_F4V10.book Page 91 Tuesday, July 3, 2018 1:03 PM
Downloaded from ManualsNet.com search engine

Yamaha AR190 2019 Specifications

General

Seating Capacity	8 persons
Hull Material	Fiberglass
Horsepower	180 hp
Beam	8 ft 2 in
Draft	15 in (0.38 m)
Engine	Yamaha 1.8L High Output
