Yamaha AR190 2019 User Manual

Equipment operation
70
Side table
The side table can be installed in front of the
rear starboard seat.
1 Side table
To install the side table, slide the end of the
table pole into the table bracket until it is
locked in place.
1 Table bracket
2 Table pole
3 Table bracket knob
To remove the side table, pull the table brack-
et knob, and then pull the table pole upward.
Wakeboard tower
(AR195/AR190)
The wakeboard tower is provided as an ele-
vated tow point suitable for wakeboards and
similar towable recreational equipment. The
tow pylon can be used to attach a standard
ski rope or other tow-rope.
WARNING
Severe injury or death can result if you ig-
nore any of the following:
 Maximum towing capacity:
1 Person, 158 kg (350 lb) max.
 Make sure the tow-rope is securely fas-
tened to the tow pylon on the wake-
board tower.
 Do not tow a tube or other inflatable
from the wakeboard tower. Use the ski
tow hook on the transom.
 Stay clear of the tow-rope while pulling
a wakeboard rider or skier.
 Do not climb, hang, or sit on the wake-
board tower.
 Make sure all knobs securing the wake-
board tower are tightened before opera-
tion and check periodically during use.
1
1
3
2
SportsBoat_F4V10.book Page 70 Tuesday, July 3, 2018 1:03 PM
Downloaded from ManualsNet.com search engine

Yamaha AR190 2019 Specifications

General

Seating Capacity	8 persons
Hull Material	Fiberglass
Horsepower	180 hp
Beam	8 ft 2 in
Draft	15 in (0.38 m)
Engine	Yamaha 1.8L High Output
