6D93G11
8-6
1
2
3
4
5
6
7
8
9
Top view
1
Fuel injection
2
Shift position switch
3
Sensor assembly
(intake air temperature and intake air
pressure)
4
Idle speed control
5
Stator coil
6
Power trim and tilt switch
7
Starter motor
S6D88040
1
3
4
2
5
6
7
Electrical components
