SPEC
Specifications
2-7
6D93G11
ECM output peak voltage
(B/R, B/W – Ground)
at cranking (loaded) V 210
at 1,500 r/min (loaded) V 290
at 3,500 r/min (loaded) V 290
Pulser coil output peak voltage
(W/R, W/B – B)
at cranking (unloaded) V 3.6
at cranking (loaded) V 3.4
at 1,500 r/min (loaded) V 18.2
at 3,500 r/min (loaded) V 34.3
Pulser coil resistance
(*)
(W/R, W/B – B)
Ω
459–561
Throttle position sensor
Output voltage (P – B) V 0.8–1.2 at engine idle speed
Cooling water temperature
sensor resistance
at 0 °C (32 °F) k
Ω
5.21–6.37
at 80 °C (176 °F) k
Ω
0.290–0.354
Oil pressure switch
Operating pressure kPa
(kgf/cm
2
, psi)
127.5–166.7 (1.28–1.67, 18.49–24.17)
Fuel control system
Fuel injector resistance
(*)
at 21 °C (70 °F)
Ω
12.0
Starter motor
Type Sliding gear
Output kW 1.40
Cranking time limit Second 30
Brushes
Standard length mm (in) 15.5 (0.61)
Wear limit mm (in) 9.5 (0.37)
Commutator
Standard diameter mm (in) 29.0 (1.14)
Wear limit mm (in) 28.0 (1.10)
Mica
Standard undercut mm (in) 0.8 (0.03)
Wear limit mm (in) 0.2 (0.01)
(*)
The figures are for reference only.
Item Unit
Model
F80BET F100DET
